Stock# 44345
New 2025 Behnke FB8X27SDPT-40L Equipment Tag Trailer
Our highly popular tag-style 40,000 lb. – 50,000 lb. deckover tilt is perfect for loading the heaviest equipment in your fleet. These models come standard air brakes and our custom 1-piece fabricated I-beam construction that produces a higher tensile strength beam than the steel mills produce. 24’ tilt decks come standard, then you are able to choose between a 4’ – 10’ stationary deck to fit whatever equipment you plan to haul on it. Various traction options are also available to give you some extra stability for loading on wet and muddy days.
Model:FB8X27SDPT-40L
Warranty:
Super Duty Flatbed Trailer – Tandem Axle – Pull-type
GVW: 40,000 lb.
Bed Length: 21’
Beavertail: 6’ Self-Cleaning Angle Iron with (2) 23" Wide x 6' Long Self-Cleaning Angle Iron Ramps (spring-loaded both directions)
Width: 8’6”
Construction: 1 Piece I-beam (80 ksi web and T1 flanges)
Axles & Suspension
(1) 22,500 lb. axle w/ ABS Air Brakes, Spring Ride
(1) 22,500 lb. axle Non-ABS Air Brake, Spring Ride
Hutch 9700 Spring Suspension
Tires & Wheels
(8) 235/75R-17.5 Tire (16-ply) w/ Dual Wheels
Wheels: "Black" steel wheels
Hitch & Deck
3" Adjustable Pintle Hitch (Rated at 66,000 lbs.)
Oak Deck (screwed down with heavy-duty 5/16" screws)
Deck Height: Approx. 35" when unloaded, 33" when fully loaded
Frame & Structure
Tongue Mount Toolbox
(2) Dual Speed Semi-Style Landing Gear
Solid Front Rail, 6" High
4" Jr. I-beam Crossmembers on 16" centers
8" x 11.5 lb. Channel Side Rail
1/4" Steel Over the Wheels
Safety & Features
D-rings every 4’ (see options page for stake pockets & rub rail)
(2) 1/2" Grade 70 Transporter Safety Chains
Rubber Mounted LED Lights
Amber Center Turn Lights, 1 each side
Step with Handle on Driver’s Side
Mud Flaps
Reflector Tape
Zinc Rich Primed and Powder Coated
We offer outstanding financing options, accept trades, and can arrange nationwide NO HASSLE delivery!
Inquire today for more information! (888) 333-6613
**We believe these specifications to be accurate. Any discrepancies are unintentional. Please verify information with a sales associate prior to purchase.**
