Stock# 44780
New 2025 Horizon Trailers FYZ 32'X102"X34" GN 12K 2A HYD DOVETAIL Flatdeck Trailer
The FYZ Gooseneck Flatdeck Hydraulic Dovetail Trailer is built for serious hauling and reliability, offering a GVWR range from 25K to 30K and your choice of 10K, 12K, or 16K tandem axles, all supported by a rugged 12" bridged I-beam frame. Its 102" wide deck, 34" height, and 12' hydraulic dovetail with a 13° tilt make loading smooth and efficient. Standard features include a Neckboss 12" engineered I-beam tongue, tandem side-wind drop-leg jacks, a mega lockable toolbox, and a wireless remote hydraulic system. Finished in durable powdercoat with multiple color options and DOT-approved LED lighting, the FYZ Gooseneck is designed to perform—and built to last.
Model:FYZ 32'X102"X34" GN 12K 2A HYD DOVETAIL
Warranty:
Axle Warranty: 6 Year Lippert Spring Axle Warranty
Trailer Warranty: 3-Year Frame, 1-Year Parts
TRAILER SPECS:
DIMENSIONS:
Available Lengths: 32'
Deck Width: 102"
Deck Height: 34"
COUPLER:
Standard Coupler: Adjustable 2-5/16" GN Coupler (30,000 lbs)
JACKS:
Front Jacks: 2 Side Wind Spring Loaded Drop Jack Legs (12,000 lbs)
TOOLBOX:
Mega Lockable Toolbox
SAFETY:
Safety Chains: 3/8" Grade 70 Safety Chain w/ Clevis Hook (2 each)
DECK:
BED:
Rear of Deck: 12' Dovetail
Deck Frame: 2" x 6" x 7ga. Tubing Bed Frame
Flooring: Pine Lumber Floor
Crossmembers: 3" Channel (3.50 lbs/ft) 16" Spacing
Deck Height: 34"
Deck Width: 102"
DOVETAIL:
Deck Frame: 2" x 6" x 7ga. Tubing Bed Frame
Flooring: Pine Lumber Floor
Crossmembers: 3" I-Beam
Deck Height: 34"
Deck Width: 102"
Dovetail Length: 12'
Hauling Capacity: 10,000 lbs When Weight Distributed Across Length Of Deck
Tilt: 13° (Tilt)
LIFT SYSTEM:
HYDRAULICS:
System: 2 Button Hydraulic - Power Up / Power Down
Pump: KTI 12V Hydraulic Pump
Controller: 14' Control Cable
Wireless Controller: Tuff Wireless 2 Button Wireless Remote
DOVETAIL:
Cylinders: 2 - 4" x 16" Single Push Cylinders
Lift Capacity: 10,000 lbs When Weight Distributed Across Length Of Deck
RUNNING GEAR:
TIRES:
12K Axles: ST235/80R16, Dual 10PR 3,080 lbs
AXLES:
12K Axle Type: 12k Lippert Electric Brake Auto Adjust Dual Oil Bath, Spring Axles 8 On 6.5"
SUSPENSION:
10K - 12K Axle: Universal Slipper Spring Hangers
We offer outstanding financing options, accept trades, and can arrange nationwide NO HASSLE delivery!
Inquire today for more information! (888) 333-6613
**We believe these specifications to be accurate. Any discrepancies are unintentional. Please verify information with a sales associate prior to purchase.**
