2020 LUCON 14' Heavy Duty Equipment Trailer



Circle M Arena
READY TO WORK FOR YOU - Southern Trailer!
The 2020 LUCO Heavy Duty Equipment Trailer Model 5T142BW-HDP has an approximate capacity of 10,000 lbs. It features a 14-foot deck length, 6-inch main frame, and two 6,000 lb. axles.
The specific technical specifications for the LUCO Model 5T142BW-HDP are detailed below:
• Capacity: 10,000 lbs.
• Overall Width: 98" (102" optional)
• Deck Length: 14'–20' Flat
• Main Frame: 6" I-Beam
• Crossmembers: 3" Channel
• Axles: (2) 6,000 Lb.
• Suspension: 12,000 Lb. Slipper
• Brakes: 12" x 2" Electric
• Tires: 235 80R 16 (8 Bolt)
• Jack: 12,000 Lb. Side Wind
• Hitch: Adjustable 2 1/2" Pintle Ring
• Tie Downs: (2) 5/8" D-Rings per side
• Lights: LED
• Wiring: Sealed Modular Harness
• Decking: 2" Nominal Oak
• Paint: CAT Yellow



Trailer information

Year2020
Pull typeBumper
Stock #Tr 122-01
Price
TypeEquipment

Contact information:

NamePaul Logan
LocationCleveland, AL
Phone205-542-9965
EmailCirclemauto1@gmail.com
Websitehttps://www.facebook.com/profile.php?id=61564766861616
