2026 Iron Eagle Trailers 7x20 10K Series Flatbed w/Ramps
2026 Iron Eagle Trailers 7x20 10K Series Flatbed w/Ramps This 2026 Iron Eagle 7x20 10K Series flatbed with ramps is built to carry heavy loads while retaining straightforward, serviceable components. The factory-default configuration is designed for general-purpose hauling of equipment, vehicles, and materials, and includes the core features listed below. Key specifications - Deck size: 7 ft wide by 20 ft long
(nominal deck dimensions
). - GVWR: 10,000 lb
(10K series rating
). - Standard 2-5/16" heavy-duty coupler for 2-5/16" ball hitches
(factory-standard for the 10K rating
). Frame and structure - Fully welded all-steel tube main frame and tongue designed for heavy-duty use. - Crossmembers and stringers sized and spaced by the factory to meet the 10K rating, welded to the main rails for a continuous load path. - Factory deck typically finished with a treated wood secured to the crossmember structure. Ramps and loading features - Ramps are stored under the trailer when not in use Axles, suspension and brakes - Tandem axles rated for the 10K GVWR
(factory-specified axles sized to meet rating
). - Electric brakes on both axles as supplied by the factory; typically includes a junction box and factory-installed brake assemblies. - Leaf-spring suspension and axle equalization configured for even load distribution. Wheels and tires - Heavy-duty radial tires mounted on factory wheels appropriate to the GVWR. - Lugs and hubs sized to the axle rating and equipped with factory grease fittings and caps. Coupler, jack and chains - Factory-installed adjustable or fixed-length tongue with a heavy-duty 2-5/16" coupler sized to the GVWR. - Drop-leg or swivel tongue jack installed at the factory to facilitate hitching and stabilizing the trailer. - Safety chains
(grade-rated
) installed at the coupler area to meet towing safety standards. Electrical and lighting - LED sealed tail/stop/turn lights and side marker lights installed to DOT specifications. - Factory wiring harness with a 7-way RV-style connector
(or manufacturer-specified connector
) for plug-in to the tow vehicle. - Breakaway battery and switch system factory-installed where required by regulation; battery and box mounted per factory standard. Finish and corrosion protection - Factory-applied finish, typically a paint over primer, applied to prepared bare metal to protect from corrosion. - Welds and high-wear areas treated and finished at the factory to resist chipping and rust during normal use. Tie-downs and accessory points - Factory-installed stake pockets, rub rail, around the deck perimeter for securing loads
(exact configuration varies by model/option but basic tie-down provisions are standard
). Fenders - Steel or formed fenders installed over tandem axles to protect tires and cargo. - Rear license plate bracket and light, reflectors, and DOT-compliant markings installed at the factory. Trailer weight: 2,334#
We also service all brands of trailers & tractors.
