2026 Big Tex Trailers 14XD 7X14 15,400 GVWR
The Big Tex 14XD is a heavy-duty tandem axle dump trailer with a 14,000-15,400 lb GVWR, available in lengths like 14ft, featuring 7,000lb axles, 8" I-beam frame, 7-gauge floor, electric brakes, LED lights, and options for 2ft or 4ft high sides and combo gates. Key specs include a 12,000lb jack, ST235/80 R-16 Load Range G tires, and a standard tool box, with varying payload depending on specific configuration. Key Specifications GVWR: 14,000 lbs or 15,400 lbs
(depending on configuration
). Axles: Two 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs. Brakes: Forward Self-Adjusting Electric Brakes on all hubs. Frame: 8" I-Beam
(10# or 13#
), integral with frame. Floor: 7 Gauge Smooth Steel. Deck Width: 83 inches
(approx. 7 ft
). Length: 14 feet
(deck length
). Tires: ST235/80 R-16 Load Range G. Jack: 12,000# Drop-Leg Jack. Gate: Combo Gate
(Barn Doors & Spreader Gate
). Battery: 12V Deep Cycle with 5A on-board charger. Features & Options Sides: 24"
(2ft
) or 4ft high options available. Ramps: 6' Slide-in Ramps with integrated ramp door. Lighting: L.E.D. D.O.T. Stop, Tail, Turn & Clearance. Storage: Full Tongue Tool Box with Locking Lid. Coupler: 2-5/16" Adjustable Ball, Demco EZ Latch. Suspension: Multi-Leaf Spring w/ Equalizer.
We also service all brands of trailers & tractors.
