2026 Big Tex Trailers 22GN-30D5A 22K 25+5 Flatbed GN Trailer w/Mega Ramp
2026 Big Tex 22GN 25+5 Gooseneck Flatbed Trailer
(22K GVWR
) Built for serious hauling, the 2026 Big Tex 22GN 25+5 Gooseneck Flatbed is a heavy-duty, professional-grade trailer designed to handle demanding jobs with confidence. Whether you’re transporting equipment, vehicles, or construction materials, this model delivers the strength, stability, and reliability Big Tex is known for. With a 22,000 lb GVWR class
(commonly rated up to 23,900 lbs
), this tandem dual-wheel gooseneck offers exceptional hauling capability while maintaining a low-profile deck for easier loading. This specific 25’ + 5’ dovetail configuration provides ample deck space and loading flexibility, making it ideal for skid steers, tractors, and other heavy equipment. Key Specs: GVWR: 23,900 lbs
(22K class
) Empty Weight: ~7,460 lbs Payload Capacity: ~16,400 lbs Deck Length: 25’ flat + 5’ dovetail Width: 102”
(8’6”
) Axles: Dual 10,000 lb heavy-duty axles Deck Height: Approx. 34” low-profile design Features & Highlights: Heavy-duty pierced I-beam frame for strength and reduced deck height Adjustable heavy-duty suspension for smoother hauling under load Mega ramps or dovetail options for easy equipment loading Dual landing gear for stability and durability LED lighting and sealed wiring harness for reliability Integrated tie-down points, rub rail, and stake pockets Why Choose the 22GN: The Big Tex 22GN series is engineered for contractors, equipment haulers, and hotshot operators who need maximum durability and payload without stepping up to a larger triple-axle trailer. Its combination of strength, versatility, and proven design makes it one of the most popular gooseneck flatbeds in its class.
We also service all brands of trailers & tractors.
