2027 Big Tex Trailers 22GN-25D5A 20+5 Gooseneck w/Mega Ramps 23.9K GVWR
New 2027 Big Tex 22GN-25 Tandem Dual Flatbed Gooseneck w/Mega Ramps When you need a serious equipment trailer built for heavy-duty hauling, the 2027 Big Tex 22GN-25 is ready to work. This tandem dual gooseneck features a 25' bed with 5' dovetail and Mega Ramps, giving you a wide, stable loading surface for tractors, skid steers, excavators, construction equipment and more. With a 23,900 lb. GVWR and approximately 17,210 lbs. of carrying capacity, the 22GN combines impressive payload capability with Big Tex's rugged low-profile pierced I-beam frame design. Features & Specifications: 25' Bed – approximately 20' flat deck + 5' dovetail 102" deck width GVWR: 23,900 lbs. Empty Weight: Approx. 6,690 lbs. Carrying Capacity: Approx. 17,210 lbs.
(2
) 10,000 lb. tandem dual axles Oil-bath hubs Forward self-adjusting electric brakes on both axles Heavy-duty 30,000 lb. adjustable suspension 5' Mega Ramps for a wide, stable loading surface 2-5/16" Demco EZ Latch adjustable gooseneck coupler Dual 2-speed landing gear Heavy-duty 12" I-beam frame Treated pine wood deck Heavy-duty rub rail, stake pockets and chain spools Lockable front storage area with chain holder Retractable side steps LED lighting Deck work lights Spare tire mount Tandem dual-wheel design for heavy-duty hauling Whether you're hauling a tractor, skid steer, excavator or other heavy equipment, the Big Tex 22GN gives you the strength, capacity and loading versatility needed to get the job done. Empty Weight: Approx. 6,690 lbs. GVWR: 23,900 lbs. Approx. Carrying Capacity: 17,210 lbs.
We also service all brands of trailers & tractors.
